The wires that connect the two ends of the row, creating a continuity in the support for the plants that have to be grown, shall be able to provide necessary support for the fixing and fastening of the system. The wires should be kept perfectly tight and kept in tension throughout the period of use, averagely for 30 years, and shall be able to bear the stress and loads to which the structures are subject such as the mechanical harvesting, the weight of the production of fruit and grapes, wind, rain and hail.
The company offers a wide range of wire products to meet the farmers’ needs.
TRIPLE WIRE ZINC (STRETCHING 20%)
It starts with a wire coating having classic triple hot dip galvanizing with a resistance of 400/500 N / mm2 and elongation of 20%. Each skein is 25 kg.
Based on the diameter you need, the thread develops in:
ø 1.80 a skein of 25 Kg. develops 1,250 linear meters
ø 2.00 a skein of 25 Kg. develops 1000 linear meters
ø 2.20 a skein of 25 Kg. develops 825 linear meters
ø 2.40 a skein of 25 Kg. develops 700 linear meters
ø 2.70 a skein of 25 Kg. develops 550 linear meters
ø 3.00 a skein of 25 Kg. develops 450 linear meters
on request we can provide even larger diameters such as ø 3.5 / 4.00 / 4.50 / 5.00) these are made in rolls of 40 kg.
CHARACTERISTICS
|
diam
|
R compl (kg/min)
|
Tensile Strength(N/mm2)
|
Development n (m/kg
|
|
1,60
|
150
|
450
|
63
|
|
1,80
|
190
|
450
|
50
|
|
2,00
|
235
|
450
|
40
|
|
2,20
|
284
|
450
|
33
|
|
2,40
|
339
|
450
|
28
|
|
2,70
|
429
|
450
|
22
|
|
3,00
|
529
|
450
|
18
|
|
3,50
|
721
|
450
|
13
|
|
4,00
|
942
|
450
|
10
|
WIRE ZINC / ALUMINIUM (EXTENSION 3/5% AND EXTENSIONS 8/10%)
The wire coated with a zinc aluminum alloy in zinc and aluminum. The high content of carbon guarantees excellent performances in terms of resistance and conservation of mechanical and physical characteristics of the wire for the duration of the installation. The low elongation reduces the need for tightening interventions that are in any case very practical if you use a wire stretcher. The wire zinc / alluminuo is coated with a layer of zinc (95%) and aluminum (5%), which makes the material highly resistant to corrosion so that the wire has a duration equal to that of the plant.
The wire zinc / allumininio can 'be with lengthening 3/5% elongation or with 8/10%
The wire zinc / aluminum extension 3/5% has a resistance 1,100 / 1,300 N / mm2
Based on the diameter you need, the thread develops in:
ø 1.60 a skein of 25 Kg. develops 1,575 linear meters
ø 1.80 a skein of 25 Kg. develops 1,250 linear meters
ø 2.00 a skein of 25 Kg. develops 1000 linear meters
ø 2.20 a skein of 25 Kg. develops 825 linear meters
ø 2.40 a skein of 25 Kg. develops 700 linear meters
ø 2.70 a skein of 25 Kg. develops 550 linear meters
ø 3.00 a skein of 25 Kg. develops 450 linear meters
on request we can provide even larger diameters such as ø 3.5 / 4.00 / 4.50 / 5.00) these are made in rolls of 40 kg.
CHARACTERISTICS
|
diam
|
R compl (kg/min)
|
Tensile Strength(N/mm2)
|
Development n (m/kg)
|
|
1,60
|
261
|
1270
|
63
|
|
1,80
|
330
|
1270
|
50
|
|
2,00
|
408
|
1270
|
40
|
|
2,20
|
493
|
1270
|
33
|
|
2,40
|
587
|
1270
|
28
|
|
2,70
|
743
|
1270
|
22
|
|
3,00
|
918
|
1270
|
18
|
|
3,50
|
1250
|
1270
|
13
|
|
4,00
|
1632
|
1270
|
10
|
The wire zinc / aluminum elongation 8/10% has a resistance 700/900 N / mm2
Based on the diameter you need, the thread develops in:
ø 1.60 a skein of 25 Kg. develops 1,575 linear meters
ø 1.80 a skein of 25 Kg. develops 1,250 linear meters
ø 2.00 a skein of 25 Kg. develops 1000 linear meters
ø 2.20 a skein of 25 Kg. develops 825 linear meters
ø 2.40 a skein of 25 Kg. develops 700 linear meters
ø 2.70 a skein of 25 Kg. develops 550 linear meters
ø 3.00 a skein of 25 Kg. develops 450 linear meters
on request we can provide even larger diameters such as ø 3.5 / 4.00 / 4.50 / 5.00) these are made in rolls of 40 kg.
WIRE steel AISI 304 (EXTENSION 2%)
For those who want a high wire resistance and outstanding performance. In stainless steel AISI 304 with high carbon content with the addition of noble elements such as chromium, nickel and manganese, the wire is resistant to atmospheric and chemical agents. This wire is, therefore, it indicated in areas with particularly aggressive environmental conditions, such as close to the sea or of centers industrial pollutants. Further features of the wire is the low elongation, which reduces the need for tightening interventions. The steel used for the wire is able to provide excellent resistance to fatigue stress, such as ligatures and twisting for locking.
The steel wire is recommended for those who have an elongation content and has high tensile strengths.
It's feasible in rolls of 25 kg or in coils of 15 kg.
Based on the weight of the coil / bobbin the thread develops in:
ø 1,20 develops 113 linear meters per kg.
ø 1,40 develops 90 linear meters per kg.
ø 1,60 develops 63 linear meters per kg.
ø 1,80 develops 50 linear meters per kg.
ø 2,00 develops 40 linear meters per kg.
ø 2,50 develops 25 linear meters per kg.
ø 2,70 develops 22 linear meters per kg.
ø 3,00 develops 18 linear meters per kg.
CHARACTERISTICS
|
diam
|
R compl (kg/min)
|
Tensile Strength(N/mm2)
|
Development n(m/kg)
|
|
1,20
|
203
|
1759
|
113
|
|
1,40
|
276
|
1757
|
90
|
|
1,60
|
341
|
1662
|
63
|
|
1,80
|
419
|
1614
|
50
|
|
2,00
|
502
|
1566
|
40
|
|
2,40
|
700
|
1516
|
25
|
|
3,00
|
989
|
371
|
17,5
|
